Technical Data:

Type :- A1/A2
Standard :- BS 6121 : Part 1/BS EN 50262
Application :- Brass Indoor & Outdoor cable gland for use with all type unarmoured cable. This gland provides a seal on outer sheath.
Ingress Protection :- IP66 EN 60529 : 2001
Material :- Brass BS 2874, CZ121
Finish :- Brass or Nickel Plated
Seal Material :- Thermoplastic Elastomer
Cable Type :- Unarmoured
Sealing Technique :- Displacement type
Sealing Area :- Outer Sheath
